VSG6G1C Vector Signal Generator
Status: Manufactured
Price: $699 USD (price does not include shipping & handling, tariff, and taxes that are applicable based on your location)
Order Info:
Avialiable on eBay(Click Here).
We do not use eBay Global Shipping Program
We ship world wide!
| *Please order using this button for shipping adresses in Canada/USA. | *Please order using this button for shipping adresses in other countries. |
*If you require overnight shipping or any other custom options on your order please send us a email at [email protected]
Specification:
Frequency Range: 1MHz to 6.1GHz (RF band) 100Hz to 1MHz (Low band), 1Hz resolution, 0.5PPM clock accuracy.
Output level range: -100dBm~+10dBm (1MHz ~4GHz), -100dBm~+0dBm (4GHz ~6.1GHz), -50dBm~0dBm (Low band), 0.25dB resolution.
Working mode: CW mode, frequency sweeping, frequency hopping, pulse modulation and simultaneous I&Q modulation(100KB data buffer).
Analog modulation: AM, FM, PM.
Digital modulation: ASK, FSK, 4FSK, GFSK, MSK, GMSK, SFSK, and more modulation signal based on the I&Q engine.
Phase modulation: BPSK, 4PSK, 8PSK, 16QAM, 32QAM, 64QAM and more modulation signal based on the I&Q engine.
Low band function: Sin wave, I&Q modulation,arbitrary signal waveform (raw data file) and modulated any low band signal into RF signal with AM, FM and PM.
Pulse signal modulation:pulse width 0.25us~5s, repeat time: 40us~20S(single frequency), 400us~20s (Sweeping and hopping)
Dimensions: 100mm x 25mm x 25mm (L x W x H)
Features:
Probe size USB device, with N connector and solid metal case
I&Q connector provides I&Q input and output
Intuitive PC program GUI inspired by desktop instrument front panel
Provides I&Q engine for easy generation of many useful modulations
Multi-modulation solutions achieving simulation of: TDMA, CDMA , hopping
system, and most of the useful systems
Built-in arbitrary function generator to Low band signal output
Pulse output at rear panel for Synchronization or work as Pulse generator
Extra Low cost, extra low weight, best performance for price
Reference clock input and output
USB type C port without extra battery pack Standalone working with only 5V power.
Offline work only with 5V source power.
